Zoom H2essesntial Multi-Mic Handy Recorder

( 0 Reviews )
Rs. 18,552.00 Rs. 16,099.00

Inclusive of all GST

Specs

Inputs

MID mic (FRONT/REAR) Pickup pattern Unidirectional
  Sensitivity –37 dB/Pa at 1 kHz
  Maximum sound pressure input 120 dB SPL
SIDE mic Pickup pattern Bidirectional
  Sensitivity –39 dB/Pa at 1 kHz
  Maximum sound pressure 122 dB SPL
MIC/LINE IN jack Connector Stereo mini jack
  Input impedance 2 kΩ
  Maximum input level −7 dBu
  Plug-in power 3.3 V


Outputs

PHONE/LINE OUT jack Connector Stereo mini jack
  Maximum output level 20 mW + 20 mW (when 32 Ω load)
  Output impedance 10 Ω or less
Built-in speaker Type 20 mm × 30 mm elliptical dynamic speaker
  Effective maximum output 250 mW


Recorder

Recording format WAV
  44.1, 48 or 96 kHz / 32-bit float
  Stereo / mono
  BWF and iXML formats supported
Recording media microSDHC memory cards
  microSDXC memory cards


Display

1.3" full-color LCD   240 × 240


USB

Connector   USB Type-C
    • Use a USB cable that supports data transfer.
Audio interface   USB2.0 High Speed
  Input and output channels 4 in / 2 out (Multi)
    2 in / 2 out (Stereo)
  Sampling frequencies 44.1/48/96 kHz (audio interface only)
    44.1/48 kHz (audio interface + onboard recording)
  Bit depths 24-bit, 32-bit float
File transfer   USB2.0 High Speed


Power

2 AA batteries Alkaline, Lithium, or Rechargeable NiMH
AC adapter ZOOM AD-17: DC 5 V/1 A
  • USB bus power is supported.


ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES (FRONT stereo recording)

Alkaline batteries About 11 hours
NiMH batteries (1900 mAh) About 9 hours
Lithium batteries About 20.5 hours


FRONT stereo recording at 48 kHz/32-bit float, no headphones or remote, Power Saving time set to 1 minute
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.

ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES (FRONT+REAR stereo recording)

Alkaline batteries About 8 hours
NiMH batteries (1900 mAh) About 8 hours
Lithium batteries About 17.5 hours


FRONT+REAR stereo recording at 48 kHz/32-bit float, no headphones or remote, Power Saving time set to 1 minute
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.

ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES (FRONT stereo + external mic recording)

Alkaline batteries About 4 hours
NiMH batteries (1900 mAh) About 4.5 hours
Lithium batteries About 9.5 hours


load) and remote, Power Saving time set to 1 minute
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.

Power consumption 3 W maximum
Dimensions 60 mm (W) × 44 mm (D) × 97 mm (H)
Weight (including batteries) 170 g


Note: 0 dBu = 0.775 Vrms

Details

Features

  • Mid-Side stereo pickup from the front and rear
  • Pickup pattern selection: 120°, 90°, and MONO
  • 32-bit float recording requires no gain adjustment
  • 3.5mm stereo mini external mic/line input
  • 3.5mm stereo mini line/headphone output
  • Built-in speaker for quick preview
  • Built-in Mixer for volume adjustments
  • Color 1.3-inch LCD display
  • Low-cut filter
  • Accessibility for the visually impaired
  • 32-bit float USB mic functionality for Win/Mac/iOS/Android
  • Remote control from iOS app via BTA-1 Bluetooth connection
  • Micro SDHC / micro SDXC cards up to 2TB supported
  • Powered by 2 AA batteries, AC adapter, or USB mobile battery
  • 11 hours of operation with 2 AA alkaline batteries
