Zoom A1 FOUR Acoustic Instrument Multi-Effect Processor

( 0 Reviews )

Rs. 16,299.00 Rs. 12,647.00

Inclusive of all GST

SPECS

A1 FOUR/A1X FOUR

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS	5
USER PATCHES	50
SAMPLING FREQUENCY	44.1 kHz
A/D CONVERSION	24-bit, 128× oversampling
D/A CONVERSION	24-bit, 128× oversampling
SIGNAL PROCESSING	32-bit
DISPLAY	128x32 dot matrix LCD

INPUT

INPUT	Standard mono phone jack Rated input level: -20 dBuInput impedance (line): 470 kΩ
AUX IN	Stereo mini jack Rated input level: -10 dBuInput impedance (line): 1kΩ

OUTPUT

OUTPUT	Standard stereo phone jack (combined line/headphone) Maximum output level: Line +2 dBu (10 kΩ or more output impedance)Headphones 17 mW + 17 mW (32Ω load)
INPUT S/N	120dB
NOISE FLOOR (RESIDUAL NOISE)	-97 dBu
POWER	AC adapter: 9V DC 500mA center negative (ZOOM AD-16) 4 AA batteries (about 18 hours continuous operation time when using alkaline batteries with the LCD backlight off)
USB	USB MIDI, USB Micro-B Power can also be supplied through the USB port.When using a cable designed only for power, other USB functions cannot be used.
EXTERNAL DIMENSIONS	A1 FOUR Height: 156 mm (D) × 130 mm (W) × 42 mm (H)Weight: 340 g (excluding batteries)A1X FOUR Height: 156 mm (D) × 216 mm (W) × 52 mm (H)Weight: 610 g (excluding batteries)

MAA-1

INPUT	INPUT XLR balanced input (2: hot) Input gain: +3 – +30 dBInput impedance: 10 kΩMaximum input level: +4 dBu+48V phantom power
OUTPUT	Standard mono phone jack Nominal output level: −20 dBuMaximum output level: +7 dBuOutput impedance: 1 kΩ
POWER	2 AA batteries Continuous operation time (when phantom current is 3 mA) About 15 hours (using alkaline batteries) About 15 hours (using nickel metal hydride batteries)
EXTERNAL DIMENSIONS	Height: 177 mm (D) × 23 mm (W) × 25 mm (H) Weight : 70 g (excluding batteries) 0 dBu = 0.775 V

zoom, acoustic,effects

A1 FOUR

For Acoustic Guitar, Saxophone, Trumpet, Violin, Harmonica, Acoustic Bass, and More

With specially engineered effects, built-in looper and drum machine, the A1/A1X FOUR is the first Multi-Effects Processor designed for a variety of acoustic string and wind instruments.

Features

A1 FOUR offers over 80 built-in effects
Dedicated effects for acoustic guitar, saxophone, trumpet, violin, and harmonica
Up to 5 effects can be used simultaneously, chained together in any order
50 memory locations for storing user-created patches
Looper for recording up to 30 seconds / 64 beats of CD-quality audio with seamless start & end times
68 built-in rhythm patterns tailored for unplugged styles of music
Onboard chromatic tuner

Zoom,acoustic,effects

Extraordinary Effects

The A1/A1X FOUR is preloaded with over 80 effects, including more than 35 new groundbreaking effects designed and engineered for acoustic instruments.

zoom, guitar,

Unlock the Potential of Your Acoustic Guitar

Add a multitude of warm and rich tones to your guitar. From live “unplugged” performance sounds to the finger-playing style of country and blues, there’s so much to choose from. Gorgeous effects and acoustic guitar modeling will take your instrument to places it’s never been before.

Add depth and dimension with acoustic emulators and modeling. Refresh your instrument’s natural sound, allowing your live performances to sound just like your studio recordings. Select and hone in on the tone of your favorite guitar make and style. IR (Impulse Response) technology is used to capture the sonic fingerprint all guitar shapes and bodies available on the A1 FOUR and via Guitar Lab. Each AG MODEL can be adjusted with 4 parameters (Gain, Bass, Mid, Treble) to control the volume and refine the audio output of your modeled sound.


Give Your Sax an Entirely New Soundscape Perform that gritty, rock-and-roll sax growl. Or use the lush custom-chorus effect to emulate the sound of jazz fusion. The A1/A1X Four gives sax players a soundscape of possibilities. The all-new “SaxChorus” effect delivers a more natural double-track and thick tone response by softening the modulated sensation typical of a chorus designed for the electric guitar. With ready-made settings for EQ and Compressors your sax will preserve its acousticly warm sound, even when amplified through mics.	Take Your Trumpet Back to the Future From the bright sound of electric jazz to our signature Auto Wah sound effect, the A1/A1X gives you inspiration for any style you play. With the “Tp MD70” preset patch the Pedal Wah sound is tuned, resonates and adapts to the low frequency range and curve of the Trumpet.	Turn Your Violin Into an Orchestra From the rich, full sound of a string symphony to the raw, distorted explosion of metal, the A1/A1X FOUR have effects for every genre.	More Body for Your Harmonica’s Soul Play punchy, mid-range sounds of a blues harp, or experiment with your own new sounds. Breathing new life into your harmonica has never been so much fun. Play through the preset patch “Hm StevieW” and get that famous harmonica sound as the chorus’s wet signal effect is modified to fit the frequency response of the chromatic harmonica. The A1/A1X even provides you with a truly effective simulation of the Bullet Mic, also known by harmonica players as the Green Bullet. Select the preset patch “Hm Juke” and now hear the legendary amplified, warm tone of the Green Bullet come to life, even when using any standard vocal microphone.

zoom,effects,pedal,sax

zoom,effects,trumpet

zoom, violin,effects

zoom,effects,acoustic

Give Your Sax an Entirely New Soundscape

Perform that gritty, rock-and-roll sax growl. Or use the lush custom-chorus effect to emulate the sound of jazz fusion. The A1/A1X Four gives sax players a soundscape of possibilities. The all-new “SaxChorus” effect delivers a more natural double-track and thick tone response by softening the modulated sensation typical of a chorus designed for the electric guitar. With ready-made settings for EQ and Compressors your sax will preserve its acousticly warm sound, even when amplified through mics.

Take Your Trumpet Back to the Future

From the bright sound of electric jazz to our signature Auto Wah sound effect, the A1/A1X gives you inspiration for any style you play. With the “Tp MD70” preset patch the Pedal Wah sound is tuned, resonates and adapts to the low frequency range and curve of the Trumpet.

Turn Your Violin Into an Orchestra

From the rich, full sound of a string symphony to the raw, distorted explosion of metal, the A1/A1X FOUR have effects for every genre.

More Body for Your Harmonica’s Soul

Play punchy, mid-range sounds of a blues harp, or experiment with your own new sounds. Breathing new life into your harmonica has never been so much fun. Play through the preset patch “Hm StevieW” and get that famous harmonica sound as the chorus’s wet signal effect is modified to fit the frequency response of the chromatic harmonica. The A1/A1X even provides you with a truly effective simulation of the Bullet Mic, also known by harmonica players as the Green Bullet. Select the preset patch “Hm Juke” and now hear the legendary amplified, warm tone of the Green Bullet come to life, even when using any standard vocal microphone.


Take Your Upright Bass to New Heights With focused highs and rich lows, the A1/A1X Four gives you control and flexibility from classical to rockabilly and all styles in between. Add octaves, select your piezo effect or create your own unique signature sound.	Drums & Percussion Included Choose from 68 rhythm patterns designed for acoustic music including Samba, Reggae, and Jazz. Play along with a variety of time signatures.	Guitar Lab Supported With a free download, ZOOM Guitar Lab software explore an endless world of patches and effects. And with its added ability to edit effects and arrange patches designed for Acoustic Instruments, you can experiment and create endless combinations.	The Perfect Partner The Zoom MAA-1 mic adapter provides a hassle-free connection to the A1/A1X FOUR. It works with dynamic microphones and even provides phantom power for condenser mics. Add effects to any acoustic instrument and adjust gain settings with the MAA-1’s easy-access controls.

zoom, bass,effects

zoom, drums, loops

zoom, guitar lab, effects

zoom, acoustic,pedal

Take Your Upright Bass to New Heights

With focused highs and rich lows, the A1/A1X Four gives you control and flexibility from classical to rockabilly and all styles in between. Add octaves, select your piezo effect or create your own unique signature sound.

Drums & Percussion Included

Choose from 68 rhythm patterns designed for acoustic music including Samba, Reggae, and Jazz. Play along with a variety of time signatures.

Guitar Lab Supported

With a free download, ZOOM Guitar Lab software explore an endless world of patches and effects. And with its added ability to edit effects and arrange patches designed for Acoustic Instruments, you can experiment and create endless combinations.

The Perfect Partner

The Zoom MAA-1 mic adapter provides a hassle-free connection to the A1/A1X FOUR. It works with dynamic microphones and even provides phantom power for condenser mics. Add effects to any acoustic instrument and adjust gain settings with the MAA-1’s easy-access controls.

Details

FEATURES

A1 FOUR offers over 80 built-in effects / A1X FOUR offers over 90 built-in effects
Dedicated effects for acoustic guitar, saxophone, trumpet, violin, and harmonica
Up to 5 effects can be used simultaneously, chained together in any order
50 memory locations for storing user-created patches
Looper for recording up to 30 seconds / 64 beats of CD-quality audio with seamless start and end times
ZOOM Guitar Lab software for creating, editing and managing effects and patches
68 built-in rhythm patterns tailored for unplugged styles of music can be used in combination with the Looper
Onboard chromatic tuner supports all standard guitar tunings, including open and drop tunings
Output jack for connection to amp or headphones
A1 FOUR and A1X FOUR runs on 4 AA batteries, with alkaline battery life of 18 hours; MAA-1 Requires 2 AA batteries
USB port for firmware updates, power and connection to ZOOM Guitar Lab
