Mixars Duo Professional 2 Channel Battle Mixer for Serato DJ

DUO // TECHNICAL details 1. General section power source ac 1 00~240v 50/60hz Power consumption 13watts Dimensions 265mm (w) x 369mm (d) x 104.1mm (h) Weight 4.15kg 2. Input/output impedance & sensitivity: ( 1khz input , mic/aux, trim, master at max.) 2-1. Input impedance and reference input level: Line 10k ohm /-14dbv(200mv) Phono 47k ohm /-50dbv(3.16mv) Aux 10k ohm /-14dbv(200mv) Mic 5k ohm /-54dbv(1.99mv) (unbalance) Usb (n/a)/-3.4dbv(96k-782 tk.16/1khz -20db) 2-2. Output impedance and reference out level: nominal limited Master 1k ohm /0dbv (1v) ± 1db ± 2db Balanced 600 ohm /0dbv (1v) ± 1db ± 2db Booth 600 ohm /0dbv (1v) ± 1db ± 2db Phones 33 ohm /-3dbv (708mv) ± 1db ± 2db Record 1k ohm /-9dbv (400mv) ± 1db ± 2db 3. Frequency response: (reference input level , mic/aux, trim, master at max.) nominal limited Line 20 - 20k hz +1/-1.5db +2/-3db Aux 20 - 20k hz +1/-1.5db +2/-3db Phono 20 - 20k hz +1/-2db +2/-3db (riaa) Mic： 20 - 20k hz +1/-2db +2/-3db 4. Maximum input: ( mic/aux, trim, master at 9 o’clock. Adjust input 1khz level tooutput level less than 1% t.h.d with a-w/20khz lpf) nominal limited Line +15dbv +14dbv Aux +15dbv +14dbv Phono -21dbv -22dbv Mic -25dbv -26dbv 5. Maximum output: ( mic/aux, trim, master at max. Adjust input 1khz level to output level less than 1% t.h.d with a-w/20khz lpf ) nominal limited Master unbalanced +17 dbv +16dbv Master balanced +17 dbv +16dbv Booth balanced +17 dbv +16dbv Phones +5dbv +4dbv www.mixars.com DUO // TECHNICAL details 6. S/n ratio: ( 1khz input , mic/aux, trim, master at 12 o’clock, with a-w/20khz lpf, input short when no signal ) nominal limited Line 86db 83db at 0db input Phono 86db 83db at -36db input Aux 86db 83db at 0db input Mic 79db 75db at -40db input 7. Thd + n: ( 1khz input , mic/aux, trim, master at 12 o’clock, with a-w/20khz lpf) nominal limited Line 0.01 % 0.02 % at 0db input Aux 0.01 % 0.02 % at 0db input Phono 0.02 % 0.05 % at -36db input Mic 0.03 % 0.06 % at -40db input 8. Crosstalk: ( 1khz input , mic/aux, trim, master at 12 o’clock with a-w/ 20khz lpf, input short when no signal ) nominal limited Line 85db 82db @each channel input at 0db input Phono 85db 82db @each channel input at -36db input 9. L&r channel separation: ( 1khz input , mic/aux, trim, master at 12 o’clock with a-w/20khz lpf, input short when no signal ) nominal limited Line 85db 82db @between l and r channel at 0db input Phono 85db 82db @between l and r channel at -36db input 10. Equalizer response: ( reference input level , mic/aux, trim master at max. With20khz lpf ) Line: nominal limited (1) low band (low band reference frequency is 70hz) Maximum level +12 ± 1db ± 1.5db Minimum level -25 ± 1db ± 1.5db (2) middle band (middle band reference frequency is 1khz) Maximum level +12 ± 1db ± 1.5db Minimum level -25 ± 1db ± 1.5db (3) high band (hi band reference frequency is 13khz) Maximum level +12 ± 1db ± 1.5db Minimum level -25 ± 1db ± 1.5db 11. Audio card usb 24 bit 48 khz
