dB Technologies DVA S30N
Inclusive of all GST
Technical Data
Speaker Type
Active Bassreflex-Horn Subwoofer
Acoustical data
Frequency Response [+/- 3dB]
30 - 120 Hz
Max SPL
141 dB
Directivity
Omnidirectional, Cardiod Option with DSP setup
LF
2x18 "
Voice Coil LF
4 "
Amplifier
Amp Technology
Digipro® G2
Amp Class
Class D
Power Supply
3 kW SMPS
LF Amp
3000 W RMS
Cooling
Convection
Processor
Controller
DSP 56 bit
AD/DA Converter
DSP 24 bit/48 kHz
System Presets
X-Over,Delay
Phase
0, 180 °
Limiter
RMS, Peak, Thermal
Delay Option
0-4.5 ms internal
Crossover Frequency LF-MF
75-120Hz | steps of 5Hz
LF-Xover out slope
24 dB/Octave
Mechanics
Housing
Multiplex plywood
Housing Design
Rectangular
Handles
4x Per Side
Accessory
Dolly, Wheels 100mm,
Dust Cover, Rain Cover
Rigging Points
2xPick Points on top to fix
DRK10/20 rigging frames
Width
1100 mm (44 in)
Height
580 mm (23.2 in)
Depth
720 mm (28.8 in)
Weight
83 kg (182.98 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
