dB Technologies DVA MS12
Inclusive of all GST
Technical Data
Speaker Type
Active bass reflex flyable subwoofer
Acoustical data
Frequency Response [-6dB]
45 - 140 Hz
Frequency Response [-10dB]
40 - 165 Hz
Max SPL
131 dB
LF
12"
Voice Coil LF
3"
Directivity
Omnidirectional
Amplifier
Amp Technology
Digipro® G3
Amp Class
Class D
Power Supply
700W SMPS with PSU Auto-range (110V~ and 220V~)
LF Amp
700 W RMS (1400 W Peak)
Cooling
Convection
Processor
Controller
DSP 56 bit
AD/DA Converter
24 bit/48 kHz
Controls
X-Over frequency selection, Phase selection (0° or 180°), Outputs mode selection (Link/X-over), Mini-USB type “B” port (service data)
Limiter
Dual active, RMS/Peak, Thermal
Crossover Frequency LF-HF
90 - 120 Hz
LF X-over out slope
24 dB/Octave
Mechanics
Housing
Multiplex plywood - Polyurea painting
Handles
1x left side, 1x right side
Feet
4x Dual Position Reversable Feet (flying/stacking mode)
Fittings
M20 screw for pole mount on top side, integrated hardware with fast lock mechanics
Width
460 mm (18.1 in)
Height
430 mm (16.9 in)
Depth
385 mm (15.2 in)
Weight
26.5 kg (58.4 lbs)
Notes: The data are not binding; dBTechnologies reserves the right to modify the data at any time and without previous notice.
